ORA ATTUALE GMT:
 ---------------------------------------------------------------------------
 ----                            KWOS NET CHECK                         ----
 ---------------------------------------------------------------------------
				  192.168.2.205
 ---------------------------------------------------------------------------
Weewx apogee    : OK - pid: 14852	| Weewx Netatmo   : OK - pid: 53502
Modesmixer ADS-B: OK - pid: 58519	| fr24feed ADS-B  : OK - pid: 126370
pskmailserver   : NOT OK        	| Weewx Davis     : OK - pid: 1064
 ---------------------------------------------------------------------------
				  192.168.2.114
 ---------------------------------------------------------------------------
AAGsolo         : OK - pid: 1770	| SMBD            : OK - pid: 2015
 ---------------------------------------------------------------------------
				  192.168.2.94
 ---------------------------------------------------------------------------
Allsky          : NOT OK         	|
 ---------------------------------------------------------------------------
				  192.168.2.185
 ---------------------------------------------------------------------------
Dusty           : OK - pid: 11177	| AQI script      : NOT OK
Weewx Ecowitt   : OK - pid: 491 	|
 ---------------------------------------------------------------------------
				  192.168.2.208
 ---------------------------------------------------------------------------
GPSD            : NOT OK          	| NTPD            : NOT OK
 ---------------------------------------------------------------------------

KWOS EUMETSAT Satellite receiver status

Status of the KWOS's instrumentation and systems

System or instrument Status Problem Type of maintenance
Netatmo Weather Station
  External module broken  Replaced with an interior module
Davis Weather Station
Apogee Weather Station
E-Field Mill Scandriglia
RDF lightning radar Boltek


TOA lightning radar Blitzortung

Seismic sensor




  Under test the new QM-4.5LV
Winlink Gateway

 Powered off
APRS gateway

 Powered off
Fusion / WIRES-X Nodes

 Only IR0UGN
Clouds detector

 Humidity sensor broken  Will be repaired. Already ordered
Telescope service cam
Nigh allsky camera
Sky Quality Meter  Sometimes it stops  Added Kasa switch to reset it remotely
ADS-B receiver
NOAA APT Receiver

MSG-3 Receiver
TOA lightning radar Microsferics

Maintenance LogBook
